TC Series 4-Inch Performance Desktop Printers
TC200 + RTC thermal transfer label printer, 203 dpi, 6 ips, navy, 8MB SDRAM, 4MB Flash, USB 2.0, RTC, MicroSD card reader for memory expansion.
The TC Series can produce 4-inch-wide labels, tags or receipts at up to 6 ips, offering one of the best price-performance combinations on the desktop printer market.
Industries and Applications |
||||
 |
 |
 |
 |
 |
| Warehouse & Fulfilment | Retail | Healthcare | Product and Item | Shipping and Logistics |
 |
 |
|||
| Small Labels | Vinyl and Custom Signage | |||
The TC Series features a small footprint and the high performance that customers have come to expect from TSC. Durable, reliable and fast, TC series printers produce 4-inch-wide labels, tags or receipts at up to 6 inches per second, offering one of the best price-performance combinations on the desktop printer market.
Applications:
- Point-Of-Sale
- Product Marking
- Receipt/Coupon Printing
- Compliance Labelling
- Asset Tracking
- Document Management
- Shipping/Receiving
- Inventory Control
- Specimen Labelling
- Patient Tracking
Hardware Specifications
| Resolution | 203 dpi (8 dots/mm) |
| Print Method | Direct thermal/Thermal transfer |
| Display | LED with buttons |
| Hardwire Connectivity | Ethernet Parallel port Serial RS-232 USB |
| Enterprise Printer Management | TSC Console |
| Desktop | |
| Max. Print Speed | Up to 6 ips (152 mm/s) |
| Max. Print Width | 4.25″ (108 mm) |
| Max. Print Length | 90″ (2,286 mm) |
| RAM | 8 MB SDRAM |
| Flash | 4 MB |
| Expandable Flash | SD memory card reader; up to 4 GB |
| Optional Cutter | Guillotine cutter (full-cut) |
Media Specifications
| Internal Label Capacity | 5″ (127 mm) OD |
| Max. Media Width | 0.79″ – 4.4″ (20 – 112 mm) |
| Media Type | Continuous; Die-Cut; Black Mark; Fan-Fold; Notch |
| Max. Ribbon Length | 110 Meters |
| Ribbon Width | 1.57″ – 4.33″ (40 – 110 mm) |
| Media Core Diameter | 1″ – 1.5″ (25.4 – 38 mm) |
| Construction | Clamshell with double-walled plastic |
| Programming Languages | TSPL-EZD |
STANDARD CONFIGURATION:
TC200/TC300: Thermal transfer label printer
8MB SDRAM 4MB Flash
Connectivity: RS-232 Centronics, USB 2.0, Ethernet
microSD card reader for memory expansion
STANDARD ACCESSORIES:
Windows labelling software CD
Quick Installation Guide (QIG)
USB-cable
Power Cord
External universal switching power supply
