MH261 Series Industrial Barcode Printer
A Feature-Rich MH Family Beyond Your Expectations.
The MH241/MH261 Series is TSC’s mainstream industrial barcode label printer built upon the legacy of the MH240 Series. It brings new features to those looking for solutions to address evolving business challenges from growing production line demands to increasing operational complexities. The MH241/MH261 Series is equipped with sophisticated TSC Sense Care supported by SOTI Connect and TSC Console remote printer management to monitor printer status and give warning messages to ensure maximum productivity and avoid downtime. Capable of seamless connectivity, the MH241/MH261 Series is supported by both Apple-certified MFi Bluetooth 5.0 or 802.11 a/b/g/n/ac Wi-Fi with Bluetooth 4.2 combo module that turns the barcode label printer into a connected network.
| Resolution | 8 dots/mm (203 DPI) |
| Printing method | Thermal Transfer and Direct Thermal |
| Max. print speed | 305 mm (12”)/second |
| Max. print width | 168 mm (6.61”) |
| Max. print length | 14,732 mm (580“) |
| Enclosure | Die-cast print mechanism with a large clear media view window |
| Physical dimension | 357 mm (W) x 313 mm (H) x 514 mm (D) 14.05” (W) x 12.32 (H) x 20.24” (D) |
| Weight | 17.8 kg (39.24 lbs) |
| Label roll capacity | 208.3 mm (8.2”) O.D. |
| Internal rewinder (full roll) | Internal rewinder kit (5” O.D.) (dealer option) |
| Ribbon | 450 m long, max. O.D. 81 mm, 1“ core (Ink coated outside or inside) |
| Ribbon width | 50.8 mm ~ 178 mm (2” ~ 7”) |
| Processor | 32-bit RISC CPU |
| Memory | • 512MB Flash memory • 256MB SDRAM • microSD Flash memory card reader for Flash memory expansion, up to 32 GB |
| Interface | • RS-232 • Parallel • USB 2.0 (High-speed mode) • Internal Ethernet, 10/100 Mbps • USB host *2 (Front side), for scanner or PC keyboard • GPIO (DB15F) (dealer option) • Slot-in 802.11 a/b/g/n/ac Wi-Fi with Bluetooth 4.2 combo module (dealer option) |
| Power | Auto-sensing power supply • Input: AC 100-240V, 4-2A, 50-60Hz • Output: DC 5V, 5A; DC 24V, 7A; DC 36V, 1.4A; Total 243W |
| LCD display/ Operation buttons | • Multi-language selectable • 6 operation buttons • 1 LED (with 2 LEDs Green & Red) |
| LCD | 4.3” color display, 480 x 272 pixel; Resistive touch screen |
| Sensors | • Gap transmissive sensor (Position adjustable) • Black mark reflective sensor (Bottom black mark sensor, Position adjustable) • Head open sensor • Ribbon encoder sensor • Ribbon end sensor |
| Real time clock | Standard |
| Internal font | • 8 alpha-numeric bitmap fonts • Monotype Image® true type font engine with CG Triumvirate Bold Condensed scalable font |
| Barcode | 1D barcode Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11, China Post 2D barcode PDF-417, Maxicode, DataMatrix, QR code, Aztec |
| Font & barcode rotation | 0, 90, 180, 270 degree |
| Printer language | TSPL-EZD (Compatible to EPL, ZPL, ZPL II, DPL) |
| Media type | Continuous, die-cut, black mark (Bottom side black mark only), fan-fold, notch (outside wound) |
| Media width | 50.8 ~ 172.7 mm (2“~ 6.8“) |
| Media thickness | 0.06 ~ 0.268 mm (2.36~ 11.02 mil) |
| Media core diameter | 3.81 mm / 76.2 mm (1.5”/ 3”) |
| Label length | 10 ~14,732 mm (0.39“~ 580“) |
| Environment condition | • Operation: 0~40?C (32 ~104?F), 25~85% non-condensing • Storage: -40 ~60 ?C (-40 ~140?F), 10~90% non-condensing |
| Safety regulation | FCC Class A, CE Class A, RCM Class A, UL, cUL, TÜV, CCC, KC, BIS, BSMI, EAC, Argentina S mark, Mexico CoC, ENERGY STAR® |
| Environmental concern | Comply with RoHS, WEEE |
| Accessories | • Windows labelling software CD disk • Quick start guide • USB port cable • Power cord |
| Limited warranty | • Printer: 2 years • Print head: 25 km (1 million inches) or 12 months which comes first • Platen: 50 km (2 million inches) or 12 months which comes first |
| Dealer option | • GPIO (DB15F) • Heavy-duty cutter • 802.11 a/b/g/n/ac Wi-Fi with Bluetooth 4.2 combo module (including slot-in housing) * • Peel-off kit • Internal rewinder kit (5” O.D.) |
| User option | • KP-200 Plus keyboard display unit |
